GAMESA G90-2MW 5 Used Wind Turbines Wanted
MWPS World is looking for one of their Spanish clients for 5 Gamesa G90-2MW Wind Turbines. Preferable still in operation but can also be dismantled. The machines would also be installed in Spain.
Turbines should have the following specification:
ROTOR
- Diameter 90 m
- Swept area 6,362 m2
- The rotational speed of 9.0 – 19.0 rpm
- Rotational direction Clock Wise (front view)
- Weight (incl. Hub) Approx. 36 T
- Top head mass Approx. 106 T
GENERATOR
- Type Doubly-fed machine
- Rated power 2.0 MW
- Voltage 690 V ac
- Frequency 50 Hz / 60 Hz
- Protection class IP 54
- Number of poles 4
- Rotational speed 900:1,900 rpm (rated 1,680 rpm) (50 Hz)
- 1,080:2,280 rpm (rated 2,016 rpm) (60 Hz)
- Rated Stator Current 1,500 A @ 690 V
- Power factor (standard) 0.98 CAP – 0.96 IND at partial loads and
- 1 at nominal power.
- Power factor (optional) 0.95 CAP – 0.95 IND throughout
- The power range.
- Power factor at generator output terminals, at low voltage side before the transformer
MWPS World is also interested in the following Wind Turbines:
- Used Gamesa G58-850 kW Wind Turbines
- New or used Gamesa G10x-4.5MW Wind Turbines
- New or used Gamesa G80-2.0 MW Wind Turbines
- Used Gamesa G87-2.0 MW Wind Turbines
- New or used Gamesa G52-850 kW Wind Turbines
Please provide the current location and asking price if you have any of the above available.
PLEASE NOTE
- Tire kickers and time wasters may not apply!
