INDIA – 34 x Suzlon S66
Used Wind Turbines – 1.25mW
Immediately Available
SOLD
Machines year of build
- 10 units from 2006
- 24 units from, 2007
- All 34 turbines in very good condition – Turbine availability is 100% – Service history available
- Location- South West India.
- All turbines are currently still in operation
- Price is excluding dismantling (if taken down & sold without land) – ExWorks owner’s site- India
- The site is CDM registered. Carbon credit avail – 22 crores.
Plant owners propose to sell the plant along with land due to business diversification
- For financing, current bank loan can be taken over from current owner- loan period -10 years.
- Carbon credit benefit is being paid to the buyer – 70000000/annum {7 crore)
- Ppa for 20 years
- How much being paid per kWh in rupee? Rupees- 3.40 paisa/kWh
- Generation last year? (12 months data)
- Total – 78500000. {78.5 million kWh for 34 machines in the last 12 months.}
TECHNICAL SPECIFICATION – Suzlon S66 1.25mW:
| ROTOR | |
| Rotor diameter | 66m |
| Hub height | 56m |
| Installed electrical output | 1250kw |
| Rotor swept area | 3421m2 |
| Rotational speed | 13.8/20.7 rpm |
| Rotor blade material | GRP |
| Regulation | pitch regulated |
| OPERATIONAL DATA | |
| Cut in wind speed | 3m/s |
| Rated wind speed | 14m/s |
| Cut-out wind speed | 22 m/s |
| GENERATOR | |
| Type | Asynchronous generator 4/6 pole |
| Rated output | 250/1250kW |
| Rotational speed | 1006/1506 rpm |
| Rated voltage | 690v |
| Frequency | 50 Hz |
| Insulation class | H |
| Cooling system | Air-cooled |
| Enclosure class | IP 56 |
| GEARBOX | |
| Type | Integrated 3-stage gearbox,
1 planetery& 2 helical |
| Gearbox manufacture | Winergy |
| Gear ratio | 1:74:917 |
| Nominal load | 1390kw |
| Type of cooling | Oil cooling, forced lubrication |
| YAW DRAW | |
| yaw draw system | 4 active electrical yaw motors |
| Yaw bearing | polyamide-slide bearing |
| OPERATING BRAKES | |
| Aerodynamic brake | 3 independent system with blade pitching |
| Mechanical brake | spring powered disc brake,
hydraulically released, failsafe, microprocessor controlled |
DOWNLOAD TECHNICAL SPEC SHEET:
Want to sell? Sell here
Our Sales List – Click here!
CALL NOW!
☎ +44 77 888 66 846
PLEASE NOTE
- Inspection can be arranged after signing a Letter Of Intent
- Tire kickers and time wasters may not apply!
