3 used WindMaster WM750kW
Wind Turbines Available Now
WindMaster 750-EG
- Model: 750 EG – 750KW
- Year of build: 1998
- Number of units available: 3 plus one incomplete unit (no tower and one blade missing) for spare parts
- Current Location: Europe
- Minimum order quantity: 1
- Number of turbines: 3 available immediately
- Rotor diameter: 43.4 m
- Generator capacity: 750 kW
- Shaft level: 48.2 m
- Working range: 4,5-19 m/s
- Yearly production at 6 m/s* : 1.150.000 kWh/year/turbine**
- Yearly production at 7 m/s* : 1.684.000 kWh/year/turbine**
- Yearly production at 8 m/s* : 2.184.000 kWh/year/turbine**
- Year of commissioning: 1998
- *10 min average values, according to IEA standards on hub (shaft) height
- ** Weibull factor k=2; 100% availability
Rotor blades and Rotor
- Number of blades: 2
- Material: wood-epoxy-laminate
- Tip speed: 73 m/s
- Blade length: 20.268 m
- Rotation speed: 32 rpm
- Rotor surface: 1.480 m²
Yaw system
- Type: free yaw, active yaw back-up
- Motors: 2 hydraulic low-speed motors each with gear drive
- Nacelle support: 4-point ball bearing on the toothed wheel
- Cable twist control: sensor + computer
- Power supply: hydraulic unit A, 3 kW
- Angle control: wind vane
Tower
- Tower height: 47m – 2 sections
- Construction: 2 conic round parts lower part with lifting lugs.
PLEASE NOTE
- Inspection can be arranged after signing a Letter Of Intent
- Tire kickers and time wasters may not apply!
